Camera
Name
Image Sensor
Min. Illumination
WDR
Lens
Mount
Field of View
Shutter Time
IR Distance
2MP H.265 Vandal-proof Mini Dome Network Camera
1/2.8" Progressive Scan CMOS
Color: 0.002Lux @F1.2, B/W: 0Lux with IR on
Super WDR up to 140dB
3.6mm/2.8mm/3.2mm@F1.6
M12
H87°/D102°/V48°(3.6mm), H112°/D130°/V62°(2.8mm), H105°/D123°/58°(3.2mm)
1/100000s∼1/5s
25m
Video
Max. Image Resolution
Frame Rate
Video Compression
Video Bit Rate
Image Settings
Web Access
1920×1080
30fps(1920×1080), 30fps(1280×960), 30fps(1280×720), 30fps(704×576)
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
16Kbps∼16Mbps (CBR/VBR adjustable)
Saturation/Brightness/Contrast/Sharpness
Support IE/Firefox/Chrome/Safari Browser
Audio
Audio Stream
Audio Compression
Built-in Microphone
G.711/AAC
Network
Communication
Network Storage
Network Protocols
1*RJ45 10M/100M Ethernet Port
NAS(Support NFS, SMB/CIFS)
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS
System
Storage
Advanced Function
SIP/VoIP Support
Event Trigger
Event Action
Video Analysis (Optional)
System Compatibility
Support microSD/SDHC/SDXC Card Local Storage, up to 128G
Motion Detection, Privacy Masking, Backlight Compensation, HLC, 3D-DNR, ROI, Anti-fog
Yes, Voice&Video-over-IP
Motion Detection, Network Disconnection, Audio Alarm, etc.
FTP Upload/SMTP Upload/SD Card Record/SIP Phone
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting
ONVIF Profile S & G
General
Working Temperature
Working Humidity
Power Supply
Power Consumption
Weather Proof
Housing
Dimensions
Weight
Warranty
-40℃∼60℃
0∼90%(Non-condensing)
PoE
2.5W MAX, 5W MAX (With IR on)
Up to IP67-rated for weather-resistant performance
Vandal-proof IK10-rated metal housing
118.5mmX110.8mmX65mm
500g
3/5 Years
Camera
Name
Image Sensor
Min. Illumination
WDR
Lens
Mount
Field of View
Shutter Time
IR Distance
4MP H.265 Vandal-proof Mini Dome Network Camera
1/3" Progressive Scan CMOS
Color: 0.008Lux @F1.2, B/W: 0Lux with IR on
Super WDR up to 120dB
3.6mm/2.8mm/3.2mm@F1.6
M12
H80°/D94°/V46°(3.6mm), H102°/D120°/V60°(2.8mm), H97°/D114°/V56°(3.2mm)
1/100000s∼1/5s
25m
Video
Max. Image Resolution
Frame Rate
Video Compression
Video Bit Rate
Image Settings
Web Access
2592×1520
20fps(2592×1520), 30fps(2304×1296), 30fps(1920×1080), 30fps(1280×960), 30fps(1280×720), 30fps(704×576)
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
16Kbps∼16Mbps (CBR/VBR adjustable)
Saturation/Brightness/Contrast/Sharpness
Support IE/Firefox/Chrome/Safari Browser
Audio
Audio Stream
Audio Compression
Built-in Microphone
G.711/AAC
Network
Communication
Network Storage
Network Protocols
1*RJ45 10M/100M Ethernet Port
NAS(Support NFS, SMB/CIFS)
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS
System
Storage
Advanced Function
SIP/VoIP Support
Event Trigger
Event Action
Video Analysis (Optional)
System Compatibility
Support microSD/SDHC/SDXC Card Local Storage, up to 128G
Motion Detection, Privacy Masking, Backlight Compensation, HLC, 3D-DNR, ROI, Anti-fog
Yes, Voice&Video-over-IP
Motion Detection, Network Disconnection, Audio Alarm, etc.
FTP Upload/SMTP Upload/SD Card Record/SIP Phone
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting
ONVIF Profile S & G
General
Working Temperature
Working Humidity
Power Supply
Power Consumption
Weather Proof
Housing
Dimensions
Weight
Warranty
-40℃∼60℃
0∼90%(Non-condensing)
PoE
2.5W MAX, 5.5W MAX (With IR on)
Up to IP67-rated for weather-resistant performance
Vandal-proof IK10-rated metal housing
118.5mmX110.8mmX65mm
500g
3/5 Years
Camera
Name
Image Sensor
Min. Illumination
WDR
Lens
Mount
Field of View
Shutter Time
IR Distance
5MP H.265 Vandal-proof Mini Dome Network Camera
1/2.8" Progressive Scan CMOS
Color: 0.005Lux @F1.2, B/W: 0Lux with IR on
Super WDR up to 120dB
3.6mm/2.8mm/3.2mm@F1.6
M12
H80°/D102°/V59°(3.6mm), H103°/D123°/V81°(2.8mm), H96°/D123°/V71°(3.2mm)
1/100000s∼1/5s
25m
Video
Max. Image Resolution
Frame Rate
Video Compression
Video Bit Rate
Image Settings
Web Access
2560×1920
20fps(2560×1920), 20fps(2592×1520), 30fps(2304×1296), 30fps (1920×1080), 30fps(1280×960), 30fps(1280×720), 30fps(704×576)
H.265+/H.265(HEVC)/H.264+/H.264/MJPEG
16Kbps∼16Mbps (CBR/VBR adjustable)
Saturation/Brightness/Contrast/Sharpness
Support IE/Firefox/Chrome/Safari Browser
Audio
Audio Stream
Audio Compression
Built-in Microphone
G.711/AAC
Network
Communication
Network Storage
Network Protocols
1*RJ45 10M/100M Ethernet Port
NAS(Support NFS, SMB/CIFS)
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN, 802.1x, QoS
System
Storage
Advanced Function
SIP/VoIP Support
Event Trigger
Event Action
Video Analysis (Optional)
System Compatibility
Support microSD/SDHC/SDXC Card Local Storage, up to 128G
Motion Detection, Privacy Masking, Backlight Compensation, HLC, 3D-DNR, ROI, Anti-fog
Yes, Voice&Video-over-IP
Motion Detection, Network Disconnection, Audio Alarm, etc.
FTP Upload/SMTP Upload/SD Card Record/SIP Phone
Region Entrance, Region Exiting, Advanced Motion Detection, Tamper Detection, Line Crossing, Loitering, Human Detection, People Counting
ONVIF Profile S & G
General
Working Temperature
Working Humidity
Power Supply
Power Consumption
Weather Proof
Housing
Dimensions
Weight
Warranty
-40℃∼60℃
0∼90%(Non-condensing)
PoE
2.5W MAX, 5.5W MAX (With IR on)
Up to IP67-rated for weather-resistant performance
Vandal-proof IK10-rated metal housing
118.5mmX110.8mmX65mm
500g
3/5 Years
Camera
Name
Image Sensor
Min. Illumination
WDR
Lens
Mount
Field of View
Shutter Time
IR Distance
1.3MP Vandal-proof Mini Dome Network Camera
1/3" Progressive Scan CMOS
Color: 0.01Lux @F1.2, B/W: 0Lux with IR on
WDR
3.6mm@F1.6
M12
H76.8°(3.6mm)
1/100000s-1/5s
15m
Video
Max. Image Resolution
Frame Rate
Video Compression
Video Bit Rate
Image Settings
Web Access
1280×960
30fps(1280×960), 30fps(1280×720), 30fps(704×576)
H.264/MJPEG
16Kbps∼16Mbps (CBR/VBR adjustable)
Saturation/Brightness/Contrast/Sharpness
Support IE/Firefox/Chrome/Safari Browser
Network
Communication
Network Storage
Network Protocols
1*RJ45 10M/100M Ethernet Port
NAS(Support NFS, SMB/CIFS)
IPv4/IPv6, TCP, UDP, RTP, RTSP, RTCP, HTTP, HTTPS, DNS, DDNS, DHCP, FTP, NTP, SMTP, UPnP, SIP, SNMP, PPPoE, VLAN
System
Storage
Intelligent Video
SIP/VoIP Support
Event Trigger
Event Action
System Compatibility
Support microSD/SDHC/SDXC Card Local Storage, up to 64G
Motion Detection, Privacy Mask, Backlight Compensation, 3D-DNR, ROI
Yes, Voice&Video-over-IP
Motion Detection, Network Disconnection, Audio Alarm, etc.
FTP upload/SMTP upload/SD card record/SIP Phone
ONVIF Profile S
General
Working Temperature
Working Humidity
Power Supply
Power Consumption
Weather Proof
Housing
Dimensions
Weight
Warranty
-30℃∼60℃
0∼90%(non-condensing)
PoE
3.5W MAX, 5.5W MAX (with IR on)
Up to IP67-rated for weather-resistant performance
Vandal-proof IK10-rated metal housing
110.8mmX118.5mmX65mm
500g
3 years
* Naming Convention
P - PoE Supported
B - H.265 Compression
